Dongfeng single-axle va
Product Parameters
| Dongfeng Single-Axle Box Truck Main Technical Parameters | |||
| Product Name: | Dongfeng single-axle van | External dimensions: | 7965×2455×3460,3760(mm) |
| Chassis model: | EQ1080GSZ3GJ | Cargo box dimensions: | 5600×2274×2100,2400(mm) |
| Total mass: | 7735 (Kg) | Approach/Departure Angles: | 30/14(°) |
| Rated weight: | 2990 (Kg) | Front overhang and rear overhang: | 1250/2215(mm) |
| Curb weight: | 4550 (Kg) | Maximum speed: | 95 (km/h) |
| engine | Engine manufacturers | Displacement (ml) | Power (kW) |
| YC4E140-31 YC4E160-31 ISDe140 30 ISDe160 30 EQD160-30 YC4E140-33 YC4E160-33 YC6J160-33 | Guangxi Yuchai Machinery Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Commercial Vehicle Engine Plant of Dongfeng Motor Co., Ltd. Guangxi Yuchai Machinery Co., Ltd. | 4260 4260 4500 4500 6234 4260 4260 6494 | 103 118 103 118 118 105 118 118 |
| Emission standards: | GB3847-2005,GB17691-2005 Country III | ||
| Number of axes: | 2 | Front track: | 1750, 1850/1700, 1800 (mm) |
| Wheelbase: | 4500 | Rear track: | 1700, 1800 (mm) |
| Number of tires: | 6 | Tire specifications: | 7.50-20, 8.25-20 |
| Fuel type: | diesel fuel | Number of leaf springs: | 9/11+8 |
| Axle load: | 3150/4585 | Number of passengers in the driver's cab: | 3 |
| Vehicle Notes: | The top of the carriage is sealed and cannot be opened. | ||
| Specialized features: | The body material of the box truck can be: ① corrugated iron, ② color steel plate, ③ aluminum plate, ④ aluminum alloy corrugated, ⑤ foamed insulation. Box truck options: rear door, left and right door, fully enclosed, semi-enclosed, and stake box. Scope of application: Box trucks are widely used for transporting various goods. They are suitable for major factories, supermarkets, and individuals. Optional equipment: The rear side of the box truck can be equipped with a rear hydraulic pallet, which can lift 0.5-5 tons of heavy objects. Classification (1) According to brand classification: Dongfeng box truck, Jiefang box truck, Isuzu box truck, JAC box truck, Jiangling box truck, Foton box truck. According to shape classification: single axle. Box truck, double-axle box truck, flat-head box truck, pointed-head box truck (2) Classified by type: Xiaobawang box truck, Dolica box truck, Sanpingchai box truck, Dongfeng Kangba box truck, 145 box truck, 153 box truck, 1208 box truck, 1230 box truck, 1290 box truck, semi-trailer box truck, (3) Classified by purpose: stake-type transport vehicle, box truck The structure of the cargo part is a closed box and is independent of the driver's cab. Box trucks are safer and more beautiful than ordinary trucks, and the goods will not get wet in the rain. | ||
